Wiring

8.10 Connecting a communications processor

S7-1500R/H redundant system

288 System Manual, 01/2024, A5E41814787-AF

8.10 Connecting a communications processor

Introduction

You can connect the Industrial Ethernet to the communications processor via an RJ45

interface.

Connecting Industrial Ethernet to CP 1543-1

You can find more information on connecting the Industrial Ethernet in the CP 1543-1

(https://support.industry.siemens.com/cs/de/de/view/67700710/en) operating instructions.
