Commissioning
12.3 Commissioning procedure
S7-1500R/H redundant system
362 System Manual, 01/2024, A5E41814787-AF
12.3 Commissioning procedure
Requirements
• The CPUs are in the "Factory settings" state or have been reset to factory settings. You can
find more information in the Resetting CPUs to factory settings (Page 466) section.
• The CPUs have the same article numbers.
• The SIMATIC memory cards are as delivered or have been formatted and are not write-
protected.
• The two CPUs of the S7-1500R/H redundant system have the same firmware version. You
can find more information in the Firmware update (Page 461) section.
Procedure for commissioning SIMATIC S7-1500R/H
To commission the S7-1500R/H redundant system, we recommend the following procedure:
Table 12- 1 Procedure for commissioning SIMATIC S7-1500R/H
Configure hardware in STEP 7
Section Configuration (Page 289)
2 Create user program Section Programming the S7-1500R/H
(Page 317) and STEP 7 online help
Section Installation (Page 238)
Wire the configuration (lines for supply voltage, PROFINET ring or line
topology, redundancy connections) and check it.
Section Wiring (Page 258)
Insert SIMATIC memory cards in the CPUs
Section Removing/plugging in SIMATIC
memory cards (Page 363)
Switch on CPUs, optional system power/load current supply, and dis-
tributed I/O
Section First power-on of the CPUs
(Page 366)
Section CPU pairing (Page 366)
Assign CPUs redundancy IDs
Section Redundancy IDs (Page 368)
You can find the meaning of the LEDs in
the module Equipment Manuals.
Evaluate information on the CPU displays
Section CPU display (Page 434)
Load hardware configuration and user program to the CPUs
Section Downloading projects to the
CPUs (Page 372)
The following functions are helpful:
Monitoring and modifying tags, testing
with program status, forcing, controlling
the outputs in STOP. You can find more
information in the Test and service func-
tions (Page 471) section.
