Application planning
6.8 System power supply
S7-1500R/H redundant system
System Manual, 01/2024, A5E41814787-AF
231
Reference
You can find more information on the system IP address in the section Configuration process
and in the Communication (https://support.industry.siemens.com/cs/ww/en/view/59192925)
function manual.
More information on how to set up an HMI connection to the S7-1500R/H redundant system
is available in the Communication
(https://support.industry.siemens.com/cs/ww/en/view/59192925) Function Manual.
See the following entry (https://support.industry.siemens.com/cs/ww/en/view/109781687)
for an example of how to connect an HMI device with S7-1500R/H.
6.8 System power supply
6.8.1 Use of system power supplies
Introduction
If the power fed from the CPU into the backplane bus is not sufficient to supply all connected
modules with power, then you need a system power supply (PS).
Through the redundant design of system power supply modules in the H-CPUs, it is possible
to increase the availability of the supply voltage. With sufficient dimensioning of the power
balance, the H-CPU (with the central CPs) remains in the RUN-Redundant operating state if a
power supply (or supply voltage) fails.
Slot for the system power supply
With the redundant system S7-1500R/H you may insert a maximum of 2 system power
supplies (PS) per CPU. The following rules apply:
• S7-1500R: on slot 0 and/or from slot 2
• S7-1500H: from slot 2 (only via active backplane bus)
