Technical specifications
16.3 Shipping and storage conditions
S7-1500R/H redundant system
490 System Manual, 01/2024, A5E41814787-AF
16.3 Shipping and storage conditions
Introduction
The S7-1500R/H redundant system meets the specifications regarding shippings and storage
conditions pursuant to IEC 61131-2. The following information applies to modules that are
shipped and/or stored in their original packaging.
Shipping and storage conditions for modules
Table 16- 6 Shipping and storage conditions
Free fall (in shipping package)
From 1140 to 660 hPa (corresponds to an eleva-
tion of -1000 to 3500 m)
5% to 95%, without condensation
Sinusoidal vibrations in accordance with IEC
60068-2-6
5 - 8.4 Hz: 3.5 mm
8.4 - 500 Hz: 9.8 m/s
2
Shock in accordance with IEC 60068-2-27
250 m/s
2
, 6 ms, 1000 shocks
16.4 Mechanical and climatic ambient conditions
Operating conditions
The S7-1500R/H redundant system is designed for stationary use in weather-proof locations.
The operating conditions are based on the requirements of IEC 61131-2:2017.
• OTH4
• STH4 (R/H-CPUs: Minimum ambient temperature -40 °C, minimum relative humidity 5%)
• TTH4 (R/H-CPUs: Minimum relative humidity 5%)
