Application planning

6.4 Redundancy scenarios

S7-1500R/H redundant system

System Manual, 01/2024, A5E41814787-AF

177

6.4.4 Failure of the PROFINET cable in the PROFINET ring

Introduction

The following redundancy scenario describes the effects of a defective PROFINET cable in the

PROFINET ring.

Redundancy scenario

①

Primary CPU

②

Backup CPU

③

PROFINET cable (redundancy connections, PROFINET ring) → interrupted

④

IO device ET 200MP

⑤

IO device ET 200SP

Figure 6-34 Failure of a PROFINET cable in the PROFINET ring (using S7-1500R as an example)
