Wiring
8.9 Connecting interfaces for communication with S7-1500H
S7-1500R/H redundant system
System Manual, 01/2024, A5E41814787-AF
283
Protecting LC sockets on unused synchronization modules
Protect the LC sockets when storing unused synchronization modules:
Close off the LC sockets with the blanking plugs to protect them from dirt. The
synchronization modules come with blanking plugs inserted.
NOTICE
Reduced optical performance due to dirt
Even a small amount of dirt in the LC socket can affect the quality of the signal transmission.
Dirt can lead to synchronization losses in operation.
Protect the LC sockets from contamination during storage and installation of the
synchronization modules.
8.9.2 Connecting the PROFINET ring to S7-1500H
Introduction
You connect the PROFINET ring via the RJ45 sockets of the PROFINET interfaces X1 P1R and
X1 P2R.
Accessories required
PROFINET cable for the PROFINET ring
