System overview

5.6 Software

S7-1500R/H redundant system

126 System Manual, 01/2024, A5E41814787-AF

5.6 Software

5.6.1 TIA Portal

The SIMATIC controllers are integrated into the Totally Integrated Automation Portal.

Engineering with TIA Portal offers:

• Configuration and programming

• Shared data management

• A uniform operating concept for control, visualization and drives

The TIA Portal simplifies integrated engineering in all configuration phases of a plant.

Figure 5-29 TIA Portal overview
