Accessories/spare parts
General accessories
Table B- 1 General accessories
• Rail, 160 mm (with drill holes)
• Rail, 245 mm (with drill holes)
6ES7590-1AC40-0AA0
• Rail, 482 mm (with drill holes)
• Rail, 530 mm (with drill holes)
6ES7590-1AF30-0AA0
• Rail, 830 mm (with drill holes)
• Rail, 2 000 mm (without drill holes) for cutting to length
6ES7590-1BC00-0AA0
DIN rail adapter, 10 adapters, 10 hexagon socket screws and 10
washers
• For one H-CPU and up to 8 modules (ST 1+8), as of FW version
V1.1.0
6ES7590-0BH00-0AA0
• For one H-CPU and up to 4 modules (ST 1+4), as of FW version
V1.1.0
PE connection element for rail, 2 000 mm (spare part), 20 units
4-pole connection plug for supply voltage (spare part), 10 units
U-connector (spare part), 5 units
Display module 35 mm for R-CPU (replacement part), 1 unit
Display module 35 mm (replacement part) for R-CPU from article
number 6ES7513-1RM03-0AB0, 1 unit
Cover flap 35 mm (replacement part) with cutout for dis-
play/display keys for R-CPUs as of article number 6ES7513-
Display module 70 mm for R/H CPU (replacement part), 1 unit
Display module 70 mm (replacement part) for R-CPUs from article
number 6ES7515-2RN03-0AB0, 1 unit
Cover flap 70 mm (replacement part) with cutout for dis-
play/display keys for R-CPUs as of article number 6ES7515-2RN03-
6ES7591-4BB00-0AA0
Power cable connector with coding element for power supplies
6ES7590-8AA00-0AA0
Synchronization module for CPU 1517H-3 PN, CPU 1518HF-4 PN
• Sync module 1 GB FO 10 m
• Sync module 1 GB FO 10 km
6ES7960-1FB00-0AA5
