4.20.2 Assigning parameters to the SM 422; DO 16 x AC 20-120 V/2 A
Parameter assignment
You will find a description of the general procedure for assigning parameters to digital modules
in the respective sections.
Parameters of the SM 422; DO 16 x AC 20-120 V/2 A
You will find an overview of the parameters you can set and their default settings for the SM
422; DO 16 x AC 20-120 V/2 A in the following table.
Table 4-15 Parameters of the SM 422; DO 16 x AC 20-120 V/2 A
Parameters Value range Default
2
Parameter type Scope
Enable
● Diagnostic interrupt
1
Yes/no No Dynamic Module
● Destination CPU for interrupt
1 to 4 - Static Module
Reaction to CPU STOP Substitute a value
(SV)
Keep last value
(KLV)
SV Dynamic Module
Diagnostics
● Fuse blown
Yes/no No Static Channel
Set substitution value "1" Yes/no No Dynamic Channel
1
If you use the module in ER-1/ER-2, you must set this parameter to "No" because the interrupt lines are not available in
ER-1/ER-2.
2
Only in the CR (central rack) is it possible to start up the digital modules with the default settings.
