PROFIBUS DP master interface IM 467/IM 467 FO
8
8.1 PROFIBUS DP master interface IM 467/IM 467 FO
8.1.1 Overview
Order numbers
IM 467 6ES7467-5GJ02-0AB0 (RS 485)
IM 467 FO 6ES7467-5FJ00-0AB0 (F0)
Application
PROFIBUS DP, standardized in accordance with IEC 61784-1:2002 Ed1 CP 3/1, enables rapid
communication in the field between programmable controllers, PCs and field devices. Field
devices are devices such as: ET 200 distributed I/O devices, drives, valve terminals,
switchgear and many others.
The IM 467/IM 467 FO interface module is meant to be used in an S7-400 programmable
controller. It permits the S7-400 to be connected to PROFIBUS DP.
Note
The PROFIBUS DP master interface IM 467 and IM 467 FO is not a DP master in accordance
with DVP 1.
Design
● Designed for S7-400
● Can be operated without a fan
● A maximum of 4 IM 467/IM 467 FO can be used in the central rack. There are no slot rules.
● The IM 467/IM 467 FO and the CP 443-5 Extended cannot be used together.
● The transmission rate of 9.6 Kbps to 12 Mbps can be set in steps using software
● Configuration and programming are possible via PROFIBUS DP. You should not, however,
change the PROFIBUS DP parameters.
S7-400 Automation System Module Data
Reference Manual, Ausgabe 11/2016, A5E00850736-08 363
