5.8.3 Parameters of analog output modules
Overview
Analog output modules use a subset of the parameters and value range listed in the table
below, based on their functionality. For information on subsets "supported" by specific analog
modules, refer to the section dealing with the relevant module.
The default settings apply if you have not set any parameters in STEP 7.
Table 5-42 Parameters of analog output modules
Parameters Value range Default set‐
ting
1
Parameter
type
Scope
Output
● Output type
Deactivated
voltage
current
U Static Channel
● Output range
For information on configurable measuring rang‐
es of output channels, refer to the relevant mod‐
ule description.
± 10 V
1
Only in the CR (central rack) is it possible to start up the analog modules with the default settings.
See also
Commissioning the SM 431; AI 8 x 14 Bit (Page 247)
Analog modules
5.8 Assigning parameters to analog modules
S7-400 Automation System Module Data
Reference Manual, Ausgabe 11/2016, A5E00850736-08 203
