5.4.6 Representation of analog values for resistance-type sensors
Table 5-15 Analog value representation for resistance-type sensors from 48 Ω to 6 kΩ
System Resistive transducer range
Dec. Hex. 48 Ω 150 Ω 300 Ω 600 Ω 6 kΩ
118,515 % 32767 7FFF 56.89 Ω 177.77 Ω 355.54 Ω 711.09 Ω 7.11 kΩ Overflow
117,593 % 32512 7F00
117,589 % 32511 7EFF 56.44 Ω 176.38 Ω 352.77 Ω 705.53 Ω 7.06 kΩ Overshoot
range
27649 6C01
100,000 % 27648 6C00 48 Ω 150 Ω 300 Ω 600 Ω 6 kΩ Nominal range
75 % 20736 5100 36 Ω 112.5 Ω 225 Ω 450 Ω 4.5 kΩ
0,003617 % 1 1 1.74 mΩ 5.43 mΩ 10.85 mΩ 21.70 mΩ 217.0 mΩ
0 % 0 0 0 Ω 0 Ω 0 Ω 0 Ω 0 Ω
(negative values are physically impossible) Undershoot
range
