Table 5-14 Representation of analog values in current measuring ranges 4 to 20 mA
System Current measuring range
Dec. Hex. 4 to 20 mA
118,515 % 32767 7FFF 22.96 mA Overflow
117,593 % 32512 7F00
117,589 % 32511 7EFF 22.81 mA Overshoot range
27649 6C01
Nominal range
100,000 % 27648 6C00 20 mA
75 % 20736 5100 16 mA
0,003617 % 1 1 4 mA + 578.7 nA
0 % 0 0 4 mA
- 1 FFFF Undershoot range
- 17,593 % - 4864 ED00 1.185 mA
Wire break
≤ - 17,596 % 32767 7FFF
Analog modules
5.4 Representation of analog values
