7.8 Terminating connector for IM 314
Introduction
The IM 314 of the last expansion unit of each line is terminated with the 6ES5 760-1AA11
terminating connector.
Table 7-8 Assignment of the terminator 760-1AA11
Assignment of the terminator 760-1AA11
34 50
171
Plug connection 180-Ohm resistance or jumper Plug connection
28 8
29 9
26 6
27 7
46 4
47 5
44 2
45 3
42 24
43 25
38
1
22
39 23
34
1
20
35 21
36
1
18
37 19
S5 interface IM 463-2
