Testing mechanical ambient conditions
The table below provides important information with respect to the type and scope of testing
of mechanical ambient conditions.
Table 1-7 Test for mechanical ambient conditions
Condition tested Test standard Remarks
Vibrations Vibration test in accord‐
ance with IEC 60068-2-6
(sinusoidal)
Type of vibration: frequency sweeps with a rate of
change of 1 octave/minute.
10 Hz ≤ f < 58 Hz, constant amplitude 0.075 mm
58 Hz ≤ f < 500 Hz, constant acceleration 1 g
Duration of vibration: 10 frequency sweeps per axis
in each of three axes perpendicular to each other.
Shock Shock test in accordance
with IEC 60068-2-29
Type of shock: half-sine
Severity of shock: 10 g peak value, 6 ms duration
Direction of shock: 100 shocks in each of the 3 axes
arranged vertically to each other.
Climatic ambient conditions
The S7-400 may be operated under the following climatic ambient conditions:
Table 1-8 Climatic ambient conditions
Ambient conditions Permissible range Remark
Temperature 0 to +60° C
Temperature change Max. 10° C / h
Relative humidity Max. 95% at +25° C No condensation
Barometric pressure 1080 to 795 hPa (corresponds to an elevation of
-1000 to 2000 m)
Concentration of pollutants SO
2
: < 0.5 ppm;
RH < 60%, no condensation
H
2
S: < 0.1 ppm;
RH < 60%, no condensation
Test: 10 ppm; 10 days
Test: 1 ppm; 10 days
ISA-S71.04 severity level G1; G2; G3 -
General specifications
1.4 Mechanical and ambient conditions for S7-400 operation
S7-400 Automation System Module Data
Reference Manual, Ausgabe 11/2016, A5E00850736-08 25
