Step response at an interference frequency suppression of 10 Hz
100
0
800
100
200
1600
3200
2400
Signal variation in
percent
Step response for any analog input signal
Smoothing
None:
Low:
average:
high:
Response time in ms
Figure 5-40 Step response at 10 Hz interference frequency suppression of the SM 431; AI 8 x 16 Bit
Step response at an interference frequency suppression of 50 Hz
100
0
16080
240 320
400 480 560 64040
20
Signal variation in
percent
Step response for any analog input signal
Smoothing
None:
Low:
average:
high:
Response time in ms
Figure 5-41 Step response at 50 Hz interference frequency suppression of the SM 431; AI 8 x 16 Bit
Analog modules
5.25 Analog input module SM 431; AI 8 x 16 Bit (6ES7431-7KF00-0AB0)
