Siemens Simatic S7-400

Block diagram of SM 432; AO 8 x 13 bit
D
A
24 V
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH0
L+/M
Bus control
Bus S7-400
Analog supply
Figure 5-44 Block diagram of SM 432; AO 8 x 13 bit
Analog modules
5.26 Analog output module SM 432; AO 8 x 13 Bit (6ES7432-1HF00-0AB0)
S7-400 Automation System Module Data
Reference Manual, Ausgabe 11/2016, A5E00850736-08 317
