1
2
3
4
5
Figure 6-1 Example: Configuration with send IMs, receive IMs and terminators
(1) Receive IM
(2) Terminator
(3) Receive IM
(4) Send IM
(5) CR
Interface modules
6.1 Common features of the interface modules
S7-400 Automation System Module Data
328 Reference Manual, Ausgabe 11/2016, A5E00850736-08
