Bytes 4 to 8 of the SM 421; DI 16 x DC 24 V
Table B-4 Bytes 4 to 8 of the diagnostic data of the SM 421; DI 16 x DC 24 V
Byte Bit Meaning
Byte 4 7 0
6 Channel type B#16#70: Digital input
5
4
3
2
1
0
Byte 5 7 Number of diagnostics bits that the module outputs per channel: 8 bits long
0
Byte 6 7 Number of channels of the same type in one module: 16 channels
0
Byte 7 5 Channel error 7
6 Channel error 6
5 ...
4 ...
3 ...
2 ...
1 Channel error 1
0 Channel error 0
Diagnostic data of signal modules
B.3 Diagnostic data of the digital input modules as of byte 2
