Siemens Simatic S7-400

Byte Bit Meaning
Byte 3 7 0
6 Hardware interrupt lost
5 0
4 0
3 0
2 EPROM error
1 0
0 0
Bytes 4 to 8 of the SM 421; DI 16 x UC 24/60 V
Table B-7 Bytes 4 to 8 of the diagnostic data of the SM 421; DI 16 x UC 24/60 V
Byte Bit Meaning
Byte 4 7 0
6 Channel type B#16#70: Digital input
5
4
3
2
1
0
Byte 5 7 Number of diagnostics bits that the module outputs per channel: 8 bits long
0
Byte 6 7 Number of channels of the same type in one module: 16 channels
0
Diagnostic data of signal modules
B.3 Diagnostic data of the digital input modules as of byte 2
S7-400 Automation System Module Data
410 Reference Manual, Ausgabe 11/2016, A5E00850736-08
