S7-200 SMART
System Manual, V2.3, 07/2017, A5E03822230-AF
565
Debugging and troubleshooting
STEP 7-Micro/WIN SMART provides software tools to help you debug and test your
program. These features include viewing the status of the program as it is executed by the
CPU, selecting to run the CPU for a specified number of scans, and forcing values.
Use the hardware troubleshooting guide (Page 578) as a guide for determining the cause
and possible solution when troubleshooting problems with the hardware.
Debugging your program
10.1.1
You can set bookmarks in your program to make it easy to move back and forth between
designated networks in a long program:
Click this button to set or remove a bookmark at the pro-
gram network designated by the current cursor location.
Click this button to move to the next bookmarked network of
your program.
Click this button to move to the previous bookmarked
Click this button to remove all bookmarks in your
