Technical specifications
A.4 Analog inputs and outputs expansion modules (EMs)
S7-200 SMART
System Manual, V2.3, 07/2017, A5E03822230-AF
741
Table A- 96 Connector pin locations for EM AE08 Analog 8 x Inputs (6ES7288-3AE08-0AA0)
Pin
X10 (gold)
X11 (gold)
X12 (gold)
X13 (gold)
1
L+ / 24 V DC
No connection
No connection
No connection
2 M / 24 V DC No connection No connection No connection
3
Functional Earth
No connection
No connection
No connection
4 AI 0+ AI 2+ AI 4+ AI 6+
5
AI 0-
AI 2-
AI 4-
AI 6-
6
AI 1+
AI 3+
AI 5+
AI 7+
7
AI 1-
AI 3-
AI 5-
AI 7-
A.4.2
EM AQ02 and EM AQ04 analog output module specifications
Table A- 97 General specifications
Technical data
EM Analog 2 x outputs (EM AQ02)
EM Analog 4 x outputs (EM AQ04)
Article number
6ES7288-3AQ02-0AA0
6ES7288-3AQ04-0AA0
Dimensions W x H x D (mm)
45 x 100 x 81
45 x 100 x 81
Weight
147.1 grams
170.5 grams
Power dissipation
1.5 W (no load)
2.1 W (no load)
Current consumption (SM Bus)
60 mA
60 mA
Current consumption (24 V DC)
50 mA (no load)
75 mA (no load)
90 mA (20 mA load per channel)
155 mA (20 mA load per channel)
