Siemens SIMATIC S7 - EM AM03 and EM AM06 Analog Input;Output Module Specifications

Technical specifications
A.4 Analog inputs and outputs expansion modules (EMs)
S7-200 SMART
744 System Manual, V2.3, 07/2017, A5E03822230-AF
Table A- 102 Connector pin locations for EM AQ04 Analog 4 x Outputs (6ES7288-3AQ04-0AA0)
Pin
X10 (gold)
X11 (gold)
X12 (gold)
X13 (gold)
1
L+ / 24 V DC
No connection
No connection
No connection
2 M / 24 V DC No connection No connection No connection
3
Functional Earth
No connection
No connection
No connection
4
No connection
No connection
AQ 0M
AQ 2M
5
No connection
No connection
AQ 0
AQ 2
6
No connection
No connection
AQ 1M
AQ 3M
7
No connection
No connection
AQ 1
AQ 3
A.4.3
EM AM03 and EM AM06 analog input/output module specifications
Table A- 103 General specifications
Technical data
EM 2 x Analog Inputs / 1 x Analog Out-
puts (AM03)
EM 4 x Analog Inputs / 2 x Analog Outputs
(AM06)
Article number
6ES7288-3AM03-0AA0
6ES7288-3AM06-0AA0
Dimensions W x H x D (mm)
45 x 100 x 81
45 x 100 x 81
Weight
172 grams
173.4 grams
Power dissipation
1.1 W (no load)
2.0 W (no load)
Current consumption (SM Bus)
60 mA
80 mA
Current consumption (24 V DC)
30 mA (no load)
60 mA (no load)
50 mA (20 mA load per channel)
100 mA (20 mA load per channel)
