Table 4-36 Maximum permissible axial vibration values for SH 80 to 160
1)
Vibration velocity Vibration acceleration
v
rms
= 4.5 mm/s a
peak
= 2.25 m/s
2
1) Both values must be maintained simultaneously
Figure4-66 Maximum permissible vibration velocity including vibration amplitude and vibration
acceleration for SH 80 to 160
Table 4-37 Maximum permissible axial vibration values for SH 180 to 280
1)
Vibration velocity Vibration acceleration
v
rms
= 7.1 mm/s a
peak
= 3.55 m/s
2
1) Both values must be maintained simultaneously
Mechanical properties
4.10Vibration response
1PH8 SIMOTICS M main motors
152 Con󹪝guration Manual, 12/2022, A5E51895839A
