Siemens SINUMERIK 808D User Manual

Programming and Operating Manual (Milling)
6FC5398-4DP10-0BA6, 09/2017
265
T6
M6
G43 H6 G0 Z100
S4000 M3
G00 Z50
X36 Y24.1
F100
G81 X35 Y24.1 R2 Z-4.5 F100
X43.66 Y29.1
X35 Y34.1
X26.34 Y29.1
Y19.1
X35 Y14.1
X43.66 Y19.1
G80 G0 Z100 M9
T7
M6
G43 H7 G0 Z100
S4000 M3 M8
X36 Y24.1
G83 X36 Y24.1 Z-14 R2 Q2 F100
X43.66 Y29.1
X35 Y34.1
X26.34 Y29.1
Y19.1
X35 Y14.1
X43.66 Y19.1
G0 G80 Z100 M9
T8
M6
G43 H8 G0 Z100
S500 M3 M8
X36 Y24.1
G84 X36 Y24.1 Z-14 R2 F400
X43.66 Y29.1
X35 Y34.1
X26.34 Y29.1
Y19.1
X35 Y14.1
X43.66 Y19.1
G0 G80 Z100 M9
M9
M05
M30
9. Open the window for creating a new program through the following key operations:
→
10. Enter the name of the subprogram with the file name extension, "SSG.SPF" in this ex-
