Siemens SINUMERIK 808D User Manual

Programming and Operating Manual (Milling)
334 6FC5398-4DP10-0BA6, 09/2017
Address
Significance
Value assignments
Information
Programming
CHF
Chamfer; general
use
0.001 ... 99 999.999
Inserts a chamfer of the speci-
fied chamfer length between
two contour blocks
N10 X... Y.... CHF=...
N11 X... Y...
CHR
Chamfer; in the
contour definition
0.001 ... 99 999.999
Inserts a chamfer of the speci-
fied side length between two
contour blocks
N10 X... Y.... CHR=...
N11 X... Y...
CR
Radius for circular
interpolation
0.010 ... 99 999.999
Negative sign - for
selecting the circle:
greater than semi-
circle
One possibility of defining a
circle when using G2/G3
See G2, G3
COMPCAD
Compressor ON:
Optimum surface
quality for CAD
programs
Effective: Modal
COMPCAD; separate block
COMPCUR
V
Compressor ON:
Polynomials with
constant curvature
Effective: Modal
COMPCURV; separate block
COMPOF
Compressor OFF
Effective: Modal
COMPOF; separate block
COMPON
Compressor ON
Effective: Modal
COMPON; separate block
CYCLE...
HOLES...
POCKET...
SLOT...
Machining cycle
Only specified val-
ues
Call of machining cycles re-
quires a separate block, the
provided transfer parameters
must be assigned values,
special cycle calls are possible
with additional MCALL or
CALL
CYCLE81
Drilling, centering
N5 RTP=110 RFP=100 .... ;
Assign with values
N10 CYCLE81(RTP, RFP, ...);
separate block
CYCLE82
Drilling, counterboring
N5 RTP=110 RFP=100 .... ;
Assign with values
N10 CYCLE82(RTP, RFP, ...);
separate block
CYCLE83
Deep-hole drilling
N10 CYCLE83(110, 100, ...)
;or transfer values directly;
separate block
CYCLE84
Rigid tapping
N10 CYCLE84(...) ;separate
block
CYCLE840
Tapping with compensating chuck
N10 CYCLE840(...); separate
block
CYCLE85
Reaming 1
N10 CYCLE85(...) ; separate
block
CYCLE86
Boring
N10 CYCLE86(...) ; separate
block
CYCLE802
Arbitrary positions
N10 CYCLE802(...) ; separate
block
HOLES1
Row of holes
N10 HOLES1(...); separate
block
HOLES2
Circle of holes
N10 HOLES2(...); separate
block
SLOT1
Mill slot
N10 SLOT1(...); separate
block
