Settings
Setting Meaning
Delay time for SS2/STOP C -> SOS active
p9552
Sets the transition time from STOP C to "Safe Operating Stop" (SOS).
Delay time, SLS/SOS - SLS/SOS active
p9551
Sets the delay time for the SLS changeover and for the activation of SOS for
the functions "Safely-Limited Speed"(SLS) and "Safe operating stop" (SOS).
When transitioning from a higher to a lower Safely-Limited Speed stage and
when activating a Safe Operating Stop (SOS), the "old" speed stage remains
active for this delay time. A delay is also occurred when activating SLS from
the "SOS and SLS inactive" state - and when activating SOS from the "SOS
inactive" state.
Delay time, STOP D -> SOS active
p9553
Sets the transition time from STOP D to "Safe Operating Stop" (SOS)
Delay time, STOP E -> SOS active
p9554
Sets the transition time from STOP E to "Safe Operating Stop" (SOS)
Standstill tolerance SOS
p9530
Sets the tolerance for the "Safe operating stop" function (SOS).
Commissioning and configuring
6.6 Configuring safety functions integrated in the drive
Safety Integrated (with SINAMICS S120)
Commissioning Manual, 02/2020, A5E46305916B AB 277
