Data areas
The following data areas are backed up in a commissioning archive:
Components Data Backup Setup
2)
NC data
1)
Machine data ● ●
Setting data ● ●
Option data ● ●
Global user data (GUD) ● ●
Tool and magazine data ● ●
Protection zone data ● ●
R parameters ●
Zero offsets ● ●
Workpieces, part programs and subprograms ●
Manufacturer cycles ● ●
User cycles ●
Definitions and macros ● ●
Collision avoidance data ● ●
Compensation data
● QEC - quadrant error compensation
● CEC - operation/angularity compensation
● EEC - leadscrew pitch / encoder error compensation
Note: It only makes sense to archive machine-specific
compensation data if the series commisioning file is reloa‐
ded into the same control.
●
Axis optimization data (AST) ● ●
Compile cycles ● ●
PLC data PLC project ● ●
Remanence data ●
Drive data Drive data archiving ● ●
Programs on a local
drive/NCextend
Programs contained in the user memory area.
Note: Because the user data can become very large, the
created archive file may require more storage.
The content is only backed up if it does not exceed 1 GB.
● ●
1)
For NC data, only the deviations from the standard default values are backed up. Machine data
MD11210 $MN_UPLOAD_MD_CHANGES_ONLY and MD11212 $MN_UPLOAD_CHANGES_ONLY
do not influence the archive content.
2)
The scope of data will be individualized in future software versions.
Appendix
A.4 Data backup and archiving in the SINUMERIK ONE Commissioning Tool
Safety Integrated (with SINAMICS S120)
Commissioning Manual, 02/2020, A5E46305916B AB 395
