4. The multi-edge is traversed again in a quadrant. This process is repeated until the depth
of the multi-edge has been reached.
5. The tool retracts to the safety clearance at rapid traverse.
Note
A multi-edge with more than two edges is traversed helically; with a single or double edge,
each edge is machined separately.
Procedure
1. The part program or ShopMill program to be processed has been created
and you are in the editor.
2. Press the "Milling" softkey.
3. Press the "Multi-edge spigot" and "Multi-edge" softkeys.
The "Multi-edge" input window opens.
Parameters in the "Input complete" mode
Parameters, G code program Parameters, ShopMill program
Input
● complete
PL Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V Spindle speed or constant cutting
rate
rpm
m/min
F Feedrate *
Parameter Description Unit
FZ
(only for G code)
Depth infeed rate *
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
Programming technological functions (cycles)
10.2 Milling
Milling
446 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
