Parameters in the "Input complete" mode
Parameters, G code program Parameters, ShopMill program
Input
● complete
PL Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V Spindle speed or constant cutting
rate
rpm
m/min
F Feedrate *
Parameter Description Unit
FZ
(only for ShopMill)
Depth infeed rate (only for ∇ and ∇∇∇) mm/min
in/tooth
FZ
(only for G code)
Depth infeed rate (only for ∇ and ∇∇∇) *
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
Circular pattern
● Full circle
The circumferential slots are positioned around a full circle. The distance from one
circumferential slot to the next circumferential slot is always the same and is
calculated by the control.
● Pitch circle
The circumferential slots are positioned around a pitch circle. The distance from one
circumferential slot to the next circumferential slot can be defined using angle α2.
X0
Y0
Z0
The positions refer to the center point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
N Number of grooves
R Radius of circumferential slot mm
α0 Starting angle Degrees
α1 Opening angle of the slot Degrees
α2 Advance angle - (for pitch circle only) Degrees
W Slot width mm
Z1 Slot depth (abs) or depth relative to Z0 (inc) – (only for ∇, ∇∇∇ and
∇∇∇ edge)
mm
DZ Maximum depth infeed - (only for ∇, ∇∇∇ and ∇∇∇ Rand) mm
FS Chamfer width for chamfering (inc) - (for chamfering only), mm
Programming technological functions (cycles)
10.2 Milling
Milling
458 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
