Parameter Description Unit
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only), mm
UXY Plane finishing allowance - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
Positioning Positioning motion between the slots:
● Straight line:
Next position is approached linearly in rapid traverse.
● Circular:
Next position is approached along a circular path at the feedrate defined in the
machine data.
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters ShopMill program parameters
Input
● simple
Milling direction T Tool name
RP Retraction plane mm D Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description
FZ
(only for G code)
Depth infeed rate (only for ∇ and ∇∇∇) *
FZ
(only for ShopMill)
Depth infeed rate (only for ∇ and ∇∇∇) mm/min
in/tooth
Machining The following machining operations can be selected:
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
Circular pattern
● Full circle
The circumferential slots are positioned around a full circle. The distance from one
circumferential slot to the next circumferential slot is always the same and is
calculated by the control.
● Pitch circle
The circumferential slots are positioned around a pitch circle. The distance from one
circumferential slot to the next circumferential slot can be defined using angle α2.
Programming technological functions (cycles)
10.2 Milling
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 459
