Parameter Description Unit
ZR
(for ShopMill program)
Retraction path - only for incremental retraction in mm
Align tool through beta and gamma angles
β
(for ShopMill program)
Align tool with swivel axes
● Input value
The required angle can be freely entered
● β = 0°
● β = 90°
Degrees
γ
(for ShopMill program)
● 0°
● 180°
● The required angle can be freely entered
Degrees
Directly position rotary axes
B1
(for ShopMill program)
Directly align the tool with the swiveling axes:
The required angle can be freely entered
Degrees
C1
(for ShopMill program)
The required angle can be freely entered Degrees
αC
(for ShopMill program)
Rotational position for a pole position Degrees
Hirth joint
● Round to the next Hirth joint
● Round up to Hirth joint
● Round down to Hirth joint
Note:
For machines with a Hirth joint
Tool Tool tip when swiveling
● Tracking
The position of the tool tip is maintained during swiveling.
● No tracking
The position of the tool tip is not maintained during swiveling.
Programming technological functions (cycles)
10.4 Turning - milling/turning machine
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 533
