Page #532 background imageLoading...
Page #532 background image
Parameter Description Unit
X0 Reference point X ∅ mm
Z0 Reference point Z mm
α Insertion angle Degrees
VX Cross feed ∅ (abs) or cross feed (inc) - (only for ∇∇∇ and ∇ + ∇∇∇) mm
D Maximum depth infeed – (only for ∇ and ∇ + ∇∇∇) mm
U or UX Finishing allowance in X or finishing allowance in X and Z – (only for ∇ and ∇ +
∇∇∇)
mm
UZ Finishing allowance in Z – (only for UX, ∇ and ∇ + ∇∇∇) mm
* Unit of feedrate as programmed before the cycle call
G code program (undercut, thread) parameters ShopMill program parameters
PL Machining plane T
SC Safety clearance mm D Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or
Constant cutting rate
rpm
m/min
Parameter Description Unit
TC Name of the swivel data set
Note: The selection box only appears if more than one swivel data set has been
set up.
Retraction
(for ShopMill program)
No
The axis is not retracted before swiveling
Z
Retraction in the direction of machine axis Z
Z,X,Y
Move machining axes to retraction position before swiveling
Tool direction, max.
Maximum retraction (up to the software end position) in the tool direction
Tool direction, inc.
Incremental retraction (specified retraction distance, up to the software end
position) in the tool direction
When retracting in the tool direction, in the swiveled machine state, several axes
can move (travel).
Programming technological functions (cycles)
10.4 Turning - milling/turning machine
Milling
532 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
