Parameter Description Unit
β
(for ShopMill program)
Align tool with swivel axes
● Input value
The required angle can be freely entered
● β = 0°
● β = 90°
Degrees
γ
(for ShopMill program)
● 0°
● 180°
● The required angle can be freely entered
Degrees
Directly position rotary axes
B1
(for ShopMill program)
Directly align the tool with the swiveling axes:
The required angle can be freely entered
Degrees
C1
(for ShopMill program)
The required angle can be freely entered Degrees
αC
(for ShopMill program)
Rotational position for a pole position Degrees
Hirth joint
● Round to the next Hirth joint
● Round up to Hirth joint
● Round down to Hirth joint
Note:
For machines with a Hirth joint
Tool Tool tip when swiveling
● Tracking
The position of the tool tip is maintained during swiveling.
● No tracking
The position of the tool tip is not maintained during swiveling.
Preferred direction (for
ShopMill program)
Preferred direction of the swivel axis for several possible alignments of the machine
Programming technological functions (cycles)
10.4 Turning - milling/turning machine
Milling
