Parameter Description Unit
DIR
(only G code program)
Direction of spindle rotation
S (only G code pro‐
gram)
Spindle speed rpm
V (only G code pro‐
gram)
Constant cutting rate mm/min
SV Maximum speed limit - (only for constant cutting rate V) rpm
X0 Reference point in X ∅ (abs, always diameter) mm
Z0 Reference point in Z (abs) mm
FS or R Chamfer width or rounding radius mm
X1 Depth for speed reduction ∅ (abs) or depth for speed reduction in relation to X0 (inc) mm
FR Reduced feedrate *
SR Reduced speed rpm
X2 Final depth ∅ (abs) or final depth in relation to X1 (inc) mm
* Unit of feedrate as programmed before the cycle call
Programming technological functions (cycles)
10.4 Turning - milling/turning machine
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 573
