Siemens SIPROTEC 7SD80 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
361
0A T DROPOUT DELAY Flx 0.00 .. 60.00 sec 0.00 sec Dropout Time Delay
0A BLK.by Vol.Loss Flx NO
YES
YES Block in case of Meas.-Voltage
Loss
0A DROPOUT RATIO Flx 0.70 .. 0.99 0.95 Dropout Ratio
0A DROPOUT RATIO Flx 1.01 .. 3.00 1.05 Dropout Ratio
0A DO differential Flx 0.02 .. 1.00 Hz 0.02 Hz Dropout differential
201 CT Starpoint P.System Data 1 towards Line
towards Busbar
towards Line CT Starpoint
203 Vnom PRIMARY P.System Data 1 0.4 .. 500.0 kV 10.0 kV Rated Primary Voltage
204 Vnom SECONDARY P.System Data 1 80 .. 125 V 100 V Rated Secondary Voltage (Ph-
Ph)
205 CT PRIMARY P.System Data 1 10 .. 20000 A 400 A CT Rated Primary Current
206 CT SECONDARY P.System Data 1 1A
5A
1A CT Rated Secondary Current
207 SystemStarpoint P.System Data 1 Grounded
Peterson-C.Gnd.
Isolated
Grounded System Starpoint is
220 I4 transformer P.System Data 1 Not connected
In prot. line
In prot. line I4 current transformer is
221 I4/Iph CT P.System Data 1 0.010 .. 5.000 1.000 Matching ratio I4/Iph for CT's
230 Rated Frequency P.System Data 1 50 Hz
60 Hz
50 Hz Rated Frequency
240A TMin TRIP CMD P.System Data 1 0.02 .. 30.00 sec 0.10 sec Minimum TRIP Command Dura-
tion
241A TMax CLOSE CMD P.System Data 1 0.01 .. 30.00 sec 1.00 sec Maximum Close Command Du-
ration
242 T-CBtest-dead P.System Data 1 0.00 .. 30.00 sec 0.10 sec Dead Time for CB test-autoreclo-
sure
260 Threshold BI 1 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 1
261 Threshold BI 2 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 2
262 Threshold BI 3 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 3
263 Threshold BI 4 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 4
264 Threshold BI 5 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 5
265 Threshold BI 6 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 6
266 Threshold BI 7 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 7
301 ACTIVE GROUP Change Group Group A
Group B
Group C
Group D
Group A Active Setting Group is
302 CHANGE Change Group Group A
Group B
Group C
Group D
Binary Input
Protocol
Group A Change to Another Setting
Group
402A WAVEFORMTRIGGER Osc. Fault Rec. Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
403A WAVEFORM DATA Osc. Fault Rec. Fault event
Pow.Sys.Flt.
Fault event Scope of Waveform Data
410 MAX. LENGTH Osc. Fault Rec. 0.30 .. 5.00 sec 2.00 sec Max. length of a Waveform
Capture Record
Addr. Parameter Function C Setting Options Default Setting Comments
