Siemens SIPROTEC 7SD80 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
362
411 PRE. TRIG. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.25 sec Captured Waveform Prior to
Trigger
412 POST REC. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
415 BinIn CAPT.TIME Osc. Fault Rec. 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
610 FltDisp.LED/LCD Device, General Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
615 Spont. FltDisp. Device, General NO
YES
NO Spontaneous display of flt.an-
nunciations
625A T MIN LED HOLD Device, General 0 .. 60 min; ∞ 0 min Minimum hold time of latched
LEDs
640 Start image DD Device, General image 1
image 2
image 3
image 4
image 5
image 6
image 7
image 8
image 1 Start image Default Display
650 PDI Test Mode Device, General OFF
ON
OFF PDI Test Mode
1103 FullScaleVolt. P.System Data 2 0.4 .. 500.0 kV 10.0 kV Measurem:FullScaleVolt-
age(Equipm.rating)
1104 FullScaleCurr. P.System Data 2 10 .. 20000 A 400 A Measurem:FullScaleCur-
rent(Equipm.rating)
1107 P,Q sign P.System Data 2 not reversed
reversed
not reversed P,Q operational measured values
sign
1130A PoleOpenCurrent P.System Data 2 1A 0.05 .. 1.00 A 0.10 A Pole Open Current Threshold
5A 0.25 .. 5.00 A 0.50 A
1131A PoleOpenVoltage P.System Data 2 2 .. 70 V 30 V Pole Open Voltage Threshold
1132A SI Time all Cl. P.System Data 2 0.01 .. 30.00 sec 0.10 sec Seal-in Time after ALL closures
1133A T DELAY SOTF P.System Data 2 0.05 .. 30.00 sec 0.25 sec minimal time for line open before
SOTF
1134 Line Closure P.System Data 2 only with ManCl
I OR V or ManCl
52a OR I or M/C
I or Man.Close
only with ManCl Recognition of Line Closures
with
1135 Reset Trip CMD P.System Data 2 CurrentOpenPole
Current AND 52a
Pickup Reset
CurrentOpenPole RESET of Trip Command
1150A SI Time Man.Cl P.System Data 2 0.01 .. 30.00 sec 0.30 sec Seal-in Time after MANUAL clo-
sures
1152 Man.Clos. Imp. P.System Data 2 (Setting options depend
on configuration)
None MANUAL Closure Impulse after
CONTROL
1201 87L PCC-Prot. 87 Diff. Prot. OFF
ON
ON Phase current comparison pro-
tection
1202 87L Idyn> 87 Diff. Prot. 1A 0.20 .. 20.00 A; ∞ 0.33 A Dynamic trip threshold
5A 1.00 .. 100.00 A; ∞ 1.65 A
1203 87L Idyn close> 87 Diff. Prot. 1A 0.20 .. 20.00 A; ∞ 0.33 A Dynamic trip threshold line
closure
5A 1.00 .. 100.00 A; ∞ 1.65 A
1204 87L Isteady> 87 Diff. Prot. 1A 0.50 .. 20.00 A; ∞ 1.33 A Steady pick up threshold
5A 2.50 .. 100.00 A; ∞ 6.65 A
1205 87L I min 87 Diff. Prot. 1A 0.10 .. 20.00 A; ∞ 1.00 A Minimal phase current
5A 0.50 .. 100.00 A; ∞ 5.00 A
1206 87L Trip Delay 87 Diff. Prot. 0.00 .. 0.10 sec 0.00 sec Trip Delay
1207 87L Man. Close 87 Diff. Prot. DELAYED
UNDELAYED
DELAYED Trip response after manual close
1208 87L: T EFdetect 87 Diff. Prot. 0.00 .. 32.00 sec 0.00 sec Evolving fault detect.time 1ph
faults
1214 87L:Inrush blk. 87 Diff. Prot. NO
YES
NO Inrush blocking
1221 87N L: Protect. 87 Diff. Prot. OFF
ON
Alarm Only
ON 87N L protection
Addr. Parameter Function C Setting Options Default Setting Comments
