Siemens SIPROTEC 7SD80 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
367
3407 EV. FLT. MODE 79 Auto Recl. Stops 79
starts 3p AR
is ignored
starts 3p AR Evolving fault (during the dead
time)
3408 T-Start MONITOR 79 Auto Recl. 0.01 .. 300.00 sec 0.50 sec AR start-signal monitoring time
3409 CB TIME OUT 79 Auto Recl. 0.01 .. 300.00 sec 3.00 sec Circuit Breaker (CB) Supervision
Time
3410 RemoteCl. Delay 79 Auto Recl. 0.00 .. 300.00 sec; ∞ 0.20 sec Send delay for remote close
command
3411A Max. DEAD EXT. 79 Auto Recl. 0.50 .. 300.00 sec; ∞∞sec Maximum dead time extension
3420 AR WITH DIFF 79 Auto Recl. YES
NO
YES AR with differential protection ?
3423 AR w/ INT.TRIP 79 Auto Recl. YES
NO
YES AR with intertrip ?
3424 AR w/ DTT 79 Auto Recl. YES
NO
YES AR with DTT (direct transfer trip)
3425 AR w/ 50(N)-B 79 Auto Recl. YES
NO
YES AR with 50(N)-B (back-up over-
current)
3450 1.AR:START 79 Auto Recl. YES
NO
YES Start of AR allowed in this cycle
3451 1.AR:ActionTime 79 Auto Recl. 0.01 .. 300.00 sec; ∞ 0.20 sec Action time
3453 1.AR:DeadT.1Flt 79 Auto Recl. 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3454 1.AR:DeadT.2Flt 79 Auto Recl. 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3455 1.AR:DeadT.3Flt 79 Auto Recl. 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3457 1.AR:Dead 3Trip 79 Auto Recl. 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3458 1.AR:DeadT.EV. 79 Auto Recl. 0.01 .. 1800.00 sec 1.20 sec Dead time after evolving fault
3459 1.AR:52? CLOSE 79 Auto Recl. YES
NO
NO 52-ready interrogation before re-
closing
3461 2.AR:START 79 Auto Recl. YES
NO
NO AR start allowed in this cycle
3462 2.AR:ActionTime 79 Auto Recl. 0.01 .. 300.00 sec; ∞ 0.20 sec Action time
3464 2.AR:DeadT.1Flt 79 Auto Recl. 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3465 2.AR:DeadT.2Flt 79 Auto Recl. 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3466 2.AR:DeadT.3Flt 79 Auto Recl. 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3468 2.AR:Dead 3Trip 79 Auto Recl. 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3469 2.AR:DeadT.EV. 79 Auto Recl. 0.01 .. 1800.00 sec 1.20 sec Dead time after evolving fault
3470 2.AR:52? CLOSE 79 Auto Recl. YES
NO
NO 52-ready interrogation before re-
closing
3601 81 O/U FREQ. f1 81 O/U Freq. ON: Alarm only
ON: with Trip
OFF
ON: Alarm only 81 Over/Under Frequency Prot.
element f1
3602 81-1 PICKUP 81 O/U Freq. 45.50 .. 54.50 Hz 49.50 Hz 81-1 Pickup
3603 81-1 PICKUP 81 O/U Freq. 55.50 .. 64.50 Hz 59.50 Hz 81-1 Pickup
3604 81-1 DELAY 81 O/U Freq. 0.00 .. 600.00 sec 60.00 sec 81-1 Time Delay
3611 81 O/U FREQ. f2 81 O/U Freq. ON: Alarm only
ON: with Trip
OFF
ON: Alarm only 81 Over/Under Frequency Prot.
element f2
3612 81-2 PICKUP 81 O/U Freq. 45.50 .. 54.50 Hz 49.00 Hz 81-2 Pickup
3613 81-2 PICKUP 81 O/U Freq. 55.50 .. 64.50 Hz 57.00 Hz 81-2 Pickup
3614 81-2 DELAY 81 O/U Freq. 0.00 .. 600.00 sec 30.00 sec 81-2 Time Delay
3621 81 O/U FREQ. f3 81 O/U Freq. ON: Alarm only
ON: with Trip
OFF
ON: Alarm only 81 Over/Under Frequency Prot.
element f3
3622 81-3 PICKUP 81 O/U Freq. 45.50 .. 54.50 Hz 47.50 Hz 81-3 Pickup
3623 81-3 PICKUP 81 O/U Freq. 55.50 .. 64.50 Hz 59.50 Hz 81-3 Pickup
3624 81-3 DELAY 81 O/U Freq. 0.00 .. 600.00 sec 3.00 sec 81-3 Time delay
3631 81 O/U FREQ. f4 81 O/U Freq. ON: Alarm only
ON: with Trip
OFF
ON: Alarm only 81 Over/Under Frequency Prot.
element f4
3632 81-4 PICKUP 81 O/U Freq. 45.50 .. 54.50 Hz 51.00 Hz 81-4 Pickup
3633 81-4 PICKUP 81 O/U Freq. 55.50 .. 64.50 Hz 62.00 Hz 81-4 Pickup
3634 81-4 DELAY 81 O/U Freq. 0.00 .. 600.00 sec 30.00 sec 81-4 Time delay
Addr. Parameter Function C Setting Options Default Setting Comments
