Siemens SIPROTEC 7SD80 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
368
3701 59-Vph-g Mode 27/59 O/U Volt. OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode Vph-g overvolt-
age prot.
3702 59-1-Vph PICKUP 27/59 O/U Volt. 1.0 .. 170.0 V; ∞ 85.0 V 59-1 Pickup Overvoltage (phase-
ground)
3703 59-1-Vph DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 2.00 sec 59-1 Time Delay
3704 59-2-Vph PICKUP 27/59 O/U Volt. 1.0 .. 170.0 V; ∞ 100.0 V 59-2 Pickup Overvoltage (phase-
ground)
3705 59-2-Vph DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 1.00 sec 59-2 Time Delay
3709A 59-Vph RESET 27/59 O/U Volt. 0.30 .. 0.99 0.98 Reset ratio
3711 59-Vph-ph Mode 27/59 O/U Volt. OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode Vph-ph over-
voltage prot.
3712 59-1-Vpp PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 150.0 V 59-1 Pickup Overvoltage (phase-
phase)
3713 59-1-Vpp DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 2.00 sec 59-1 Time Delay
3714 59-2-Vpp PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 175.0 V 59-2 Pickup Overvoltage (phase-
phase)
3715 59-2-Vpp DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 1.00 sec 59-2 Time Delay
3719A 59-Vpp RESET 27/59 O/U Volt. 0.30 .. 0.99 0.98 Reset ratio
3721 59G-3V0 (or Vx) 27/59 O/U Volt. OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode 3V0 overvoltage
3722 59G-1-3V0PICKUP 27/59 O/U Volt. 1.0 .. 220.0 V; ∞ 30.0 V 59G-1 Pickup 3V0 (zero seq.)
3723 59G-1-3V0 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 2.00 sec 59G-1 Time Delay
3724 59G-2-3V0PICKUP 27/59 O/U Volt. 1.0 .. 220.0 V; ∞ 50.0 V 59G-2 Pickup 3V0 (zero seq.)
3725 59G-2-3V0 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 1.00 sec 59G-2 Time Delay
3728A 59G-3Vo Stabil. 27/59 O/U Volt. ON
OFF
ON 59G: Stabilization 3Vo-Measure-
ment
3729A 59G RESET 27/59 O/U Volt. 0.30 .. 0.99 0.95 Reset ratio
3731 59-V1 Mode 27/59 O/U Volt. OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode V1 overvoltage
prot.
3732 59-1-V1 PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 150.0 V 59-1 Pickup Overvoltage (pos.
seq.)
3733 59-1-V1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 2.00 sec 59-1 Time Delay
3734 59-2-V1 PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 175.0 V 59-2 Pickup Overvoltage (pos.
seq.)
3735 59-2-V1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 1.00 sec 59-2 Time Delay
3739A 59-V1 RESET 27/59 O/U Volt. 0.30 .. 0.99 0.98 Reset ratio
3741 59-V2 Mode 27/59 O/U Volt. OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode V2 overvoltage
prot.
3742 59-1-V2 PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 30.0 V 59-1 Pickup Overvoltage (neg.
seq.)
3743 59-1-V2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 2.00 sec 59-1 Time Delay
3744 59-2-V2 PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 50.0 V 59-2 Pickup Overvoltage (neg.
seq.)
3745 59-2-V2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 1.00 sec 59-2 Time Delay
3749A 59-V2 RESET 27/59 O/U Volt. 0.30 .. 0.99 0.98 Reset ratio
3751 27-Vph-g Mode 27/59 O/U Volt. OFF
Alarm Only
ON
V<Alarm V<<Trip
OFF Operating mode Vph-g under-
voltage prot.
3752 27-1-Vph PICKUP 27/59 O/U Volt. 1.0 .. 100.0 V; 0 30.0 V 27-1 Pickup Undervoltage
(phase-neutral)
3753 27-1-Vph DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 2.00 sec 27-1 Time Delay
3754 27-2-Vph PICKUP 27/59 O/U Volt. 1.0 .. 100.0 V; 0 10.0 V 27-2 Pickup Undervoltage
(phase-neutral)
Addr. Parameter Function C Setting Options Default Setting Comments
