Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
376
275 Set Point Phase C dmd> (SP. I C
dmd>)
Set Points(MV) OUT On
Off
**LEDBO
276 Set Point positive sequence
I1dmd> (SP. I1dmd>)
Set Points(MV) OUT On
Off
**LEDBO
277 Set Point |Pdmd|> (SP. |Pdmd|>) Set Points(MV) OUT On
Off
**LEDBO
278 Set Point |Qdmd|> (SP. |Qdmd|>) Set Points(MV) OUT On
Off
**LEDBO
279 Set Point |Sdmd|> (SP. |Sdmd|>) Set Points(MV) OUT On
Off
**LEDBO
285 Set Point 55 Power factor alarm
(SP. PF(55)alarm)
Set Points(MV) OUT On
Off
**LEDBO
289 Alarm: Current summation super-
vision (Failure Σi)
Measurem.Superv OUT On
Off
* * LED BO 135 250 1 Yes
290 Alarm: Broken current-wire de-
tected L1 (Broken Iwire L1)
Measurem.Superv OUT On
Off
* * LED BO 135 137 1 Yes
291 Alarm: Broken current-wire de-
tected L2 (Broken Iwire L2)
Measurem.Superv OUT On
Off
* * LED BO 135 138 1 Yes
292 Alarm: Broken current-wire de-
tected L3 (Broken Iwire L3)
Measurem.Superv OUT On
Off
* * LED BO 135 139 1 Yes
295 Broken wire supervision is
switched OFF (Broken wire OFF)
Measurem.Superv OUT On
Off
**LEDBO
296 Current summation superv is
switched OFF (Σi superv. OFF)
Measurem.Superv OUT On
Off
**LEDBO
297 Broken current-wire at other end
ØA (ext.Brk.Wire ØA)
Measurem.Superv OUT On
Off
**LEDBO
298 Broken current-wire at other end
ØB (ext.Brk.Wire ØB)
Measurem.Superv OUT On
Off
**LEDBO
299 Broken current-wire at other end
ØC (ext.Brk.Wire ØC)
Measurem.Superv OUT On
Off
**LEDBO
301 Power System fault
(Pow.Sys.Flt.)
P.System Data 2 OUT On
Off
ON * 135 231 2 Yes
302 Fault Event (Fault Event) P.System Data 2 OUT * ON * 135 232 2 No
320 Warn: Limit of Memory Data ex-
ceeded (Warn Mem. Data)
Device, General OUT On
Off
**LEDBO
321 Warn: Limit of Memory Parameter
exceeded (Warn Mem. Para.)
Device, General OUT On
Off
**LEDBO
322 Warn: Limit of Memory Operation
exceeded (Warn Mem. Oper.)
Device, General OUT On
Off
**LEDBO
323 Warn: Limit of Memory New ex-
ceeded (Warn Mem. New)
Device, General OUT On
Off
**LEDBO
356 >Manual close signal (>Manual
Close)
P.System Data 2 SP * * * LED BI BO 150 6 1 Yes
357 >Block manual close cmd. from
external (>Blk Man. Close)
P.System Data 2 SP On
Off
**LEDBIBO15071Yes
361 >Failure: Feeder VT (MCB
tripped) (>FAIL:Feeder VT)
P.System Data 2 SP On
Off
* * LED BI BO 192 38 1 Yes
371 >Breaker 1 READY (for AR,CB-
Test) (>Bkr1 Ready)
P.System Data 2 SP * * * LED BI BO 150 71 1 Yes
378 >52 Breaker faulty (for 50BF)
(>52 faulty)
P.System Data 2 SP * * * LED BI BO
379 >52a Bkr. aux. contact (3pole
closed) (>52a 3p Closed)
P.System Data 2 SP * * * LED BI BO 150 78 1 Yes
380 >52b Bkr. aux. contact (3pole
open) (>52b 3p Open)
P.System Data 2 SP * * * LED BI BO 150 79 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
To Next Page
