A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
375
187 Error Board 5 (Error Board 5) Device, General OUT On
Off
* * LED BO 135 175 1 Yes
190 Error Board 0 (Error Board 0) Device, General OUT On
Off
* * LED BO 135 210 1 Yes
191 Error: Offset (Error Offset) Device, General OUT On
Off
**LEDBO
193 Alarm: Analog input adjustment
invalid (Alarm adjustm.)
Device, General OUT On
Off
* * LED BO 135 181 1 Yes
194 Error: Neutral CT different from
MLFB (Error neutralCT)
Device, General OUT On
Off
* * LED BO 135 180 1 Yes
196 Fuse Fail Monitor is switched
OFF (Fuse Fail M.OFF)
Measurem.Superv OUT * * LED BO 135 196 1 Yes
197 Measurement Supervision is
switched OFF (MeasSup OFF)
Measurem.Superv OUT On
Off
* * LED BO 135 197 1 Yes
234.2100 27, 59 blocked via operation (27,
59 blk)
27/59 O/U Volt. IntSP On
Off
**LEDBO
235.2110 >BLOCK Function $00 (>BLOCK
$00)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2111 >Function $00 instantaneous
TRIP (>$00 instant.)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2112 >Function $00 Direct TRIP (>$00
Dir.TRIP)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2113 >Function $00 BLOCK TRIP
Time Delay (>$00 BLK.TDly)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2114 >Function $00 BLOCK TRIP
(>$00 BLK.TRIP)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2115 >Function $00 BLOCK TRIP
Phase A (>$00 BL.TripA)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2116 >Function $00 BLOCK TRIP
Phase B (>$00 BL.TripB)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2117 >Function $00 BLOCK TRIP
Phase C (>$00 BL.TripC)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2118 Function $00 is BLOCKED ($00
BLOCKED)
Flx OUT On
Off
On
Off
**LED BO
235.2119 Function $00 is switched OFF
($00 OFF)
Flx OUT On
Off
* * * LED BO
235.2120 Function $00 is ACTIVE ($00
ACTIVE)
Flx OUT On
Off
* * * LED BO
235.2121 Function $00 picked up ($00
picked up)
Flx OUT On
Off
On
Off
**LED BO
235.2122 Function $00 Pickup Phase A
($00 pickup A)
Flx OUT On
Off
On
Off
**LED BO
235.2123 Function $00 Pickup Phase B
($00 pickup B)
Flx OUT On
Off
On
Off
**LED BO
235.2124 Function $00 Pickup Phase C
($00 pickup C)
Flx OUT On
Off
On
Off
**LED BO
235.2125 Function $00 TRIP Delay Time
Out ($00 Time Out)
Flx OUT On
Off
On
Off
**LED BO
235.2126 Function $00 TRIP ($00 TRIP) Flx OUT On
Off
on * * LED BO
235.2128 Function $00 has invalid settings
($00 inval.set)
Flx OUT On
Off
On
Off
**LED BO
273 Set Point Phase A dmd> (SP. I A
dmd>)
Set Points(MV) OUT On
Off
**LEDBO
274 Set Point Phase B dmd> (SP. I B
dmd>)
Set Points(MV) OUT On
Off
**LEDBO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
