Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
374
67 Resume (Resume) Device, General OUT ON * * LED BO 135 97 1 No
68 Clock Synchronization Error
(Clock SyncError)
Device, General OUT On
Off
**LEDBO
69 Daylight Saving Time (DayLight-
SavTime)
Device, General OUT On
Off
**LEDBO
70 Setting calculation is running
(Settings Calc.)
Device, General OUT On
Off
* * LED BO 192 22 1 Yes
71 Settings Check (Settings Check) Device, General OUT * * * LED BO
72 Level-2 change (Level-2 change) Device, General OUT On
Off
**LEDBO
73 Local setting change (Local
change)
Device, General OUT * *
110 Event lost (Event Lost) Device, General OUT_
Ev
ON * * LED BO 135 130 1 No
113 Flag Lost (Flag Lost) Device, General OUT ON * m LED BO 135 136 1 Yes
125 Chatter ON (Chatter ON) Device, General OUT On
Off
* * LED BO 135 145 1 Yes
126 Protection ON/OFF (via system
port) (ProtON/OFF)
Device, General IntSP On
Off
**LEDBO
127 79 ON/OFF (via system port) (79
ON/OFF)
79 Auto Recl. IntSP On
Off
**LEDBO
140 Error with a summary alarm
(Error Sum Alarm)
Device, General OUT On
Off
* * LED BO 192 47 1 Yes
160 Alarm Summary Event (Alarm
Sum Event)
Device, General OUT * * * LED BO 192 46 1 Yes
161 Failure: General Current Supervi-
sion (Fail I Superv.)
Measurem.Superv OUT * * * LED BO 192 32 1 Yes
163 Failure: Current Balance (Fail I
balance)
Measurem.Superv OUT On
Off
* * LED BO 135 183 1 Yes
164 Failure: General Voltage Supervi-
sion (Fail V Superv.)
Measurem.Superv OUT * * * LED BO 192 33 1 Yes
167 Failure: Voltage Balance (Fail V
balance)
Measurem.Superv OUT On
Off
* * LED BO 135 186 1 Yes
168 Failure: Voltage absent (Fail V
absent)
Measurem.Superv OUT On
Off
* * LED BO 135 187 1 Yes
169 VT Fuse Failure (alarm >10s) (VT
FuseFail>10s)
Measurem.Superv OUT On
Off
* * LED BO 135 188 1 Yes
170 VT Fuse Failure (alarm instanta-
neous) (VT FuseFail)
Measurem.Superv OUT On
Off
**LEDBO
171 Failure: Phase Sequence (Fail
Ph. Seq.)
Measurem.Superv OUT On
Off
* * LED BO 192 35 1 Yes
177 Failure: Battery empty (Fail Bat-
tery)
Device, General OUT On
Off
* * LED BO 135 193 1 Yes
181 Error: A/D converter (Error A/D-
conv.)
Device, General OUT On
Off
* * LED BO 135 178 1 Yes
182 Alarm: Real Time Clock (Alarm
Clock)
Device, General OUT
183 Error Board 1 (Error Board 1) Device, General OUT On
Off
* * LED BO 135 171 1 Yes
184 Error Board 2 (Error Board 2) Device, General OUT On
Off
* * LED BO 135 172 1 Yes
185 Error Board 3 (Error Board 3) Device, General OUT On
Off
* * LED BO 135 173 1 Yes
186 Error Board 4 (Error Board 4) Device, General OUT On
Off
* * LED BO 135 174 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
