Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
373
- >Error Control Voltage (>ErrCntr-
lV)
Process Data SP On
Off
* * LED BI BO CB 240 182 1 Yes
- >SF6-Loss (>SF6-Loss) Process Data SP On
Off
* * LED BI BO CB 240 183 1 Yes
- >Error Meter (>Err Meter) Process Data SP On
Off
* * LED BI BO CB 240 184 1 Yes
- >Transformer Temperature (>Tx
Temp.)
Process Data SP On
Off
* * LED BI BO CB 240 185 1 Yes
- >Transformer Danger (>Tx
Danger)
Process Data SP On
Off
* * LED BI BO CB 240 186 1 Yes
- Reset meter (Meter res) Energy IntSP
_Ev
ON *
- Error Systeminterface (SysIn-
tErr.)
Protocol IntSP On
Off
LED BO
- Threshold Value 1 (ThreshVal1) Thresh.-Switch IntSP On
Off
**LEDBIFC
TN
BO CB
1 No Function configured (Not con-
figured)
Device, General SP
2 Function Not Available (Non Exis-
tent)
Device, General OUT
3 >Synchronize Internal Real Time
Clock (>Time Synch)
Device, General SP * * * LED BI BO
4 >Trigger Waveform Capture
(>Trig.Wave.Cap.)
Osc. Fault Rec. SP on * m LED BI BO
5 >Reset LED (>Reset LED) Device, General SP * * * LED BI BO
7 >Setting Group Select Bit 0 (>Set
Group Bit0)
Change Group SP * * * LED BI BO
8 >Setting Group Select Bit 1 (>Set
Group Bit1)
Change Group SP * * * LED BI BO
009.0100 Failure EN100 Modul (Failure
Modul)
EN100-Modul 1 IntSP On
Off
* LED BO
009.0101 Failure EN100 Link Channel 1
(Ch1) (Fail Ch1)
EN100-Modul 1 IntSP On
Off
* LED BO
009.0102 Failure EN100 Link Channel 2
(Ch2) (Fail Ch2)
EN100-Modul 1 IntSP On
Off
* LED BO
11 >User defined annunciation 1
(>Annunc. 1)
Device, General SP * * * * LED BI BO 192 27 1 Yes
12 >User defined annunciation 2
(>Annunc. 2)
Device, General SP * * * * LED BI BO 192 28 1 Yes
13 >User defined annunciation 3
(>Annunc. 3)
Device, General SP * * * * LED BI BO 192 29 1 Yes
14 >User defined annunciation 4
(>Annunc. 4)
Device, General SP * * * * LED BI BO 192 30 1 Yes
15 >Test mode (>Test mode) Device, General SP On
Off
* * LED BI BO 135 53 1 Yes
16 >Stop data transmission
(>DataStop)
Device, General SP * * * LED BI BO 135 54 1 Yes
51 Device is Operational and Pro-
tecting (Device OK)
Device, General OUT On
Off
* * LED BO 135 81 1 Yes
52 At Least 1 Protection Funct. is
Active (ProtActive)
Device, General IntSP On
Off
* * LED BO 192 18 1 Yes
55 Reset Device (Reset Device) Device, General OUT * * * LED BO 192 4 1 No
56 Initial Start of Device (Initial Start) Device, General OUT ON * * LED BO 192 5 1 No
60 Reset LED (Reset LED) Device, General OUT_
Ev
ON * * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
