Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
380
2752 >79: External pickup 3phase for
AR start (>Pickup 3ph AR)
79 Auto Recl. SP * ON * LED BI BO 40 47 2 Yes
2781 79: Auto recloser is switched OFF
(79 OFF)
79 Auto Recl. OUT On
Off
**LEDBO40811Yes
2782 79: Auto recloser is switched ON
(79 ON)
79 Auto Recl. IntSP * * * LED BO 192 16 1 Yes
2783 79: Auto recloser is blocked (79 is
blocked)
79 Auto Recl. OUT On
Off
**LEDBO40831Yes
2784 79: Auto recloser is not ready (79
not ready)
79 Auto Recl. OUT * ON * LED BO 192 130 1 Yes
2787 79: Circuit breaker 1 not ready
(CB not ready)
79 Auto Recl. OUT * * * LED BO 40 87 1 Yes
2788 79: CB ready monitoring window
expired (79 T-CBreadyExp)
79 Auto Recl. OUT * ON * LED BO 40 88 2 Yes
2796 79: Auto recloser ON/OFF via BI
(79 on/off BI)
79 Auto Recl. IntSP * * * LED BO
2801 79 - in progress (79 in progress) 79 Auto Recl. OUT * ON * LED BO 40 101 2 Yes
2809 79: Start-signal monitoring time
expired (79 T-Start Exp)
79 Auto Recl. OUT * ON * LED BO 40 174 2 Yes
2810 79: Maximum dead time expired
(79 TdeadMax Exp)
79 Auto Recl. OUT * ON * LED BO 40 175 2 Yes
2818 79: Evolving fault recognition (79
Evolving Flt)
79 Auto Recl. OUT * ON * LED BO 40 118 2 Yes
2821 79 dead time after evolving fault
(79 Td. evol.Flt)
79 Auto Recl. OUT * On
Off
* LED BO 40 197 2 Yes
2840 79 dead time after 3pole trip
running (79 Tdead 3pTrip)
79 Auto Recl. OUT * ON * LED BO 40 149 2 Yes
2843 79 dead time after 3phase fault
running (79 Tdead 3pFlt)
79 Auto Recl. OUT * ON * LED BO 40 154 2 Yes
2844 79 1st cycle running (79 1stCyc.
run.)
79 Auto Recl. OUT * ON * LED BO 40 155 2 Yes
2845 79 2nd cycle running (79 2ndCyc.
run.)
79 Auto Recl. OUT * ON * LED BO 40 157 2 Yes
2851 79 - Close command (79 Close) 79 Auto Recl. OUT * ON m LED BO 192 128 2 No
2853 79: Close command after 3pole,
1st cycle (79 Close1.Cyc3p)
79 Auto Recl. OUT * * * LED BO 40 153 1 Yes
2854 79: Close command 2nd cycle
(and higher) (79 Close 2.Cyc)
79 Auto Recl. OUT * * * LED BO 192 129 1 No
2861 79: Reclaim time is running (79 T-
Recl. run.)
79 Auto Recl. OUT * * * LED BO 40 161 1 Yes
2862 79 - cycle successful (79 Suc-
cessful)
79 Auto Recl. OUT * * * LED BO 40 162 1 Yes
2871 79: TRIP command 3pole (79
TRIP 3pole)
79 Auto Recl. OUT * ON * LED BO 40 171 2 Yes
2889 79 1st cycle zone extension
release (79 1.CycZoneRel)
79 Auto Recl. OUT * * * LED BO 40 160 1 Yes
2890 79 2nd cycle zone extension
release (79 2.CycZoneRel)
79 Auto Recl. OUT * * * LED BO 40 169 1 Yes
2894 79 Remote close signal send (79
Remote Close)
79 Auto Recl. OUT * ON * LED BO 40 129 2 Yes
2896 No. of 1st AR-cycle CLOSE com-
mands,3pole (79 #Close1./3p=)
Statistics VI
2898 No. of higher AR-cycle CLOSE
commands,3p (79 #Close2./3p=)
Statistics VI
3102 Tolerance invalid in phase A (2nd
Harmonic A)
InRushRestraint OUT * * LED BO 92 89 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
