Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
381
3103 Tolerance invalid in phase B (2nd
Harmonic B)
InRushRestraint OUT * * LED BO 92 90 1 Yes
3104 Tolerance invalid in phase C (2nd
Harmonic C)
InRushRestraint OUT * * LED BO 92 91 1 Yes
3190 87 Set test state of 87 (Test 87) 87 Diff. Prot. IntSP On
Off
**LEDFC
TN
BO 92 106 1 Yes
3191 87 Set Commissioning state of 87
(Commiss.87)
87 Diff. Prot. IntSP On
Off
**LEDFC
TN
BO 92 107 1 Yes
3192 87 Remote relay in test state
(Test 87 remote)
87 Diff. Prot. OUT On
Off
* * LED BO 92 108 1 Yes
3193 87 Commissioning state is active
(Comm. 87 active)
87 Diff. Prot. OUT On
Off
* * LED BO 92 109 1 Yes
3197 87 >Set test state of 87 (>Test 87
ON)
87 Diff. Prot. SP On
Off
**LEDBIBO
3198 87 >Reset test state of 87 (>Test
87 OFF)
87 Diff. Prot. SP On
Off
**LEDBIBO
3199 87 Test state of 87 ON/OFF (Test
87 ON/off)
87 Diff. Prot. IntSP On
Off
**LEDBO
3200 87 Test state ON/OFF via BI (Test
87 ONoffBI)
87 Diff. Prot. IntSP On
Off
**LEDBO
3217 PDI FO data mirror (PDI FO
mirror)
Prot.Interface OUT On
Off
* LED BO
3218 PDI Cu data mirror (PDI Cu
mirror)
Prot.Interface OUT On
Off
* LED BO
3227 >PDI FO is stopped (>PDI FO
stop)
Prot.Interface SP On
Off
**LEDBIBO
3228 >PDI Cu is stopped (>PDI Cu
stop)
Prot.Interface SP On
Off
**LEDBIBO
3230 PDI FO failure (PDI FO faulty) Prot.Interface OUT On
Off
* LED BO 93 136 1 Yes
3232 PDI Cu failure (PDI Cu faulty) Prot.Interface OUT On
Off
* LED BO 93 138 1 Yes
3243 PDI FO connected to relay ID
(PDI FO con. to.)
Prot.Interface VI On
Off
*
3244 PDI Cu connected to relay ID
(PDI Cu con. to.)
Prot.Interface VI On
Off
*
3258 PDI FO telegram error rate ex-
ceeded (PDI FO TER)
Prot.Interface OUT On
Off
* LED BO
3259 PDI Cu telegram error rate ex-
ceeded (PDI Cu TER)
Prot.Interface OUT On
Off
* LED BO
3260 87 >Commissioning state ON
(>Comm. 87 ON)
87 Diff. Prot. SP On
Off
**LEDBIBO
3261 87 >Commissioning state OFF
(>Comm. 87 OFF)
87 Diff. Prot. SP On
Off
**LEDBIBO
3262 87 Commissioning state ON/OFF
(Comm 87 ON/OFF)
87 Diff. Prot. IntSP On
Off
**LEDBO
3263 87 Commissioning state ON/OFF
via BI (Comm 87 ONoffBI)
87 Diff. Prot. IntSP On
Off
**LEDBO
3270 >RESET broken wire monitoring
(>RESET BW)
Measurem.Superv SP On
Off
**LEDBIFC
TN
BO
3271 Alarm: Broken current-wire de-
tected A (Broken Iwire a)
Measurem.Superv IntSP
3272 Alarm: Broken current-wire de-
tected B (Broken Iwire b)
Measurem.Superv IntSP
3273 Alarm: Broken current-wire de-
tected C (Broken Iwire c)
Measurem.Superv IntSP
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
