Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
383
3581 Remote signal 9 received
(Rem.Sig 9 Rx)
Remote Signals OUT On
Off
* * LED BO 93 166 1 Yes
3582 Remote signal 10 received
(Rem.Sig 10 Rx)
Remote Signals OUT On
Off
* * LED BO 93 167 1 Yes
3583 Remote signal 11 received
(Rem.Sig 11 Rx)
Remote Signals OUT On
Off
* * LED BO 93 168 1 Yes
3584 Remote signal 12 received
(Rem.Sig 12 Rx)
Remote Signals OUT On
Off
* * LED BO 93 169 1 Yes
3585 Remote signal 13 received
(Rem.Sig 13 Rx)
Remote Signals OUT On
Off
* * LED BO 93 170 1 Yes
3586 Remote signal 14 received
(Rem.Sig 14 Rx)
Remote Signals OUT On
Off
* * LED BO 93 171 1 Yes
3587 Remote signal 15 received
(Rem.Sig 15 Rx)
Remote Signals OUT On
Off
* * LED BO 93 172 1 Yes
3588 Remote signal 16 received
(Rem.Sig 16 Rx)
Remote Signals OUT On
Off
* * LED BO 93 173 1 Yes
4403 >BLOCK Direct Transfer Trip
option (>BLOCK DTT)
DTT Direct Trip SP * * * LED BI BO
4417 >Direct Transfer Trip INPUT
Phases ABC (>DTT Trip ØABC)
DTT Direct Trip SP On
Off
**LEDBIBO
4421 Direct Transfer Trip is switched
OFF (DTT OFF)
DTT Direct Trip OUT On
Off
**LEDBO51211Yes
4422 Direct Transfer Trip is BLOCKED
(DTT BLOCK)
DTT Direct Trip OUT On
Off
On
Off
* LED BO 51 22 1 Yes
4435 DTT TRIP command Phases
ABC (DTT TRIP ØABC)
DTT Direct Trip OUT * ON * LED BO 51 35 2 No
5203 >BLOCK 81O/U (>BLOCK
81O/U)
81 O/U Freq. SP On
Off
* * LED BI BO 70 176 1 Yes
5206 >BLOCK 81-1 (>BLOCK 81-1) 81 O/U Freq. SP On
Off
* * LED BI BO 70 177 1 Yes
5207 >BLOCK 81-2 (>BLOCK 81-2) 81 O/U Freq. SP On
Off
* * LED BI BO 70 178 1 Yes
5208 >BLOCK 81-3 (>BLOCK 81-3) 81 O/U Freq. SP On
Off
* * LED BI BO 70 179 1 Yes
5209 >BLOCK 81-4 (>BLOCK 81-4) 81 O/U Freq. SP On
Off
* * LED BI BO 70 180 1 Yes
5211 81 OFF (81 OFF) 81 O/U Freq. OUT On
Off
* * LED BO 70 181 1 Yes
5212 81 BLOCKED (81 BLOCKED) 81 O/U Freq. OUT On
Off
On
Off
* LED BO 70 182 1 Yes
5213 81 ACTIVE (81 ACTIVE) 81 O/U Freq. OUT On
Off
* * LED BO 70 183 1 Yes
5215 81 Undervoltage Block (81
UnderV Blk)
81 O/U Freq. OUT On
Off
On
Off
* LED BO 70 238 1 Yes
5232 81-1 picked up (81-1 picked up) 81 O/U Freq. OUT * On
Off
* LED BO 70 230 2 Yes
5233 81-2 picked up (81-2 picked up) 81 O/U Freq. OUT * On
Off
* LED BO 70 231 2 Yes
5234 81-3 picked up (81-3 picked up) 81 O/U Freq. OUT * On
Off
* LED BO 70 232 2 Yes
5235 81-4 picked up (81-4 picked up) 81 O/U Freq. OUT * On
Off
* LED BO 70 233 2 Yes
5236 81-1 TRIP (81-1 TRIP) 81 O/U Freq. OUT * ON * LED BO 70 234 2 Yes
5237 81-2 TRIP (81-2 TRIP) 81 O/U Freq. OUT * ON * LED BO 70 235 2 Yes
5238 81-3 TRIP (81-3 TRIP) 81 O/U Freq. OUT * ON * LED BO 70 236 2 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
