Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
386
7257 67 Phase A forward (67 forward
ØA)
Back-Up O/C OUT * on * LED BO
7258 67 Phase B forward (67 forward
ØB)
Back-Up O/C OUT * on * LED BO
7259 67 Phase C forward (67 forward
ØC)
Back-Up O/C OUT * on * LED BO
7260 67N Gnd forward (67N forward
GND)
Back-Up O/C OUT * on * LED BO
7261 67 Phase A reverse (67 reverse
ØA)
Back-Up O/C OUT * on * LED BO
7262 67 Phase B reverse (67 reverse
ØB)
Back-Up O/C OUT * on * LED BO
7263 67 Phase C reverse (67 reverse
ØC)
Back-Up O/C OUT * on * LED BO
7264 67N Gnd forward (67N reverse
GND)
Back-Up O/C OUT * on * LED BO
7265 67(N) forward (67(N) forward) Back-Up O/C OUT * on * LED BO
7266 67(N) reverse (67(N) reverse) Back-Up O/C OUT * on * LED BO
7267 >67(N) BackupO/C Instanta-
neousTrip (>67(N) InstTRIP)
Back-Up O/C SP On
Off
On
Off
* LED BI BO
7328 CB1-TEST TRIP command ABC
(CB1-TESTtripABC)
Testing OUT On
Off
* * LED BO 153 28 1 Yes
7329 CB1-TEST CLOSE command
(CB1-TEST close)
Testing OUT On
Off
* * LED BO 153 29 1 Yes
7345 CB-TEST is in progress (CB-
TEST running)
Testing OUT On
Off
* * LED BO 153 45 1 Yes
7346 CB-TEST canceled due to Power
Sys. Fault (CB-TSTstop FLT.)
Testing OUT_
Ev
ON *
7347 CB-TEST canceled due to CB
already OPEN (CB-TSTstop
OPEN)
Testing OUT_
Ev
ON *
7348 CB-TEST canceled due to CB
was NOT READY (CB-TSTstop
NOTr)
Testing OUT_
Ev
ON *
7349 CB-TEST canceled due to CB
stayed CLOSED (CB-TSTstop
CLOS)
Testing OUT_
Ev
ON *
7350 CB-TEST was successful (CB-
TST .OK.)
Testing OUT_
Ev
ON *
10201 >BLOCK 59-Vphg Overvolt.
(phase-ground) (>59-Vphg
BLOCK)
27/59 O/U Volt. SP * * * LED BI BO
10202 >BLOCK 59-Vphph Overvolt
(phase-phase) (>59-Vphph
BLOCK)
27/59 O/U Volt. SP * * * LED BI BO
10203 >BLOCK 59-3V0 Overvolt. (zero
sequence) (>59-3V0 BLOCK)
27/59 O/U Volt. SP * * * LED BI BO
10204 >BLOCK 59-V1 Overvolt. (posi-
tive seq.) (>59-V1 BLOCK)
27/59 O/U Volt. SP * * * LED BI BO
10205 >BLOCK 59-V2 Overvolt. (nega-
tive seq.) (>59-V2 BLOCK)
27/59 O/U Volt. SP * * * LED BI BO
10206 >BLOCK 27-Vphg Undervolt.
(phase-ground) (>27-Vphg
BLOCK)
27/59 O/U Volt. SP * * * LED BI BO
10207 >BLOCK 27-Vphph Undervolt
(phase-phase) (>27-Vphph
BLOCK)
27/59 O/U Volt. SP * * * LED BI BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
