Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
385
7130 >BLOCK 50-STUB (>BLOCK 50-
STUB)
Back-Up O/C SP On
Off
**LEDBIBO64301Yes
7132 >BLOCK 50N-STUB (>BLOCK
50N-STUB)
Back-Up O/C SP On
Off
**LEDBIBO64321Yes
7152 50(N)/51(N) Backup O/C is
BLOCKED (5X-B BLOCK)
Back-Up O/C OUT On
Off
On
Off
* LED BO 64 52 1 Yes
7153 50(N)/51(N) Backup O/C is
ACTIVE (5X-B ACTIVE)
Back-Up O/C OUT * * * LED BO 64 53 1 Yes
7154 Backup O/C stage 50(N)-B2 is
sw. OFF (50(N)-B2 OFF)
Back-Up O/C OUT * * * LED BO
7155 Backup O/C stage 50(N)-B1 is
sw. OFF (50(N)-B1 OFF)
Back-Up O/C OUT * * * LED BO
7156 Backup O/C stage 50(N)-STUB is
sw. OFF (50(N)-STUB OFF)
Back-Up O/C OUT * * * LED BO
7157 Backup O/C stage 51(N)-B is sw.
OFF (51(N)-B OFF)
Back-Up O/C OUT * * * LED BO
7161 50(N)/51(N) Backup O/C
PICKED UP (5X-B PICKUP)
Back-Up O/C OUT * OFF m LED BO 64 61 2 Yes
7162 50(N)/51(N) Backup O/C
PICKUP Phase A (5X-B Pickup
ØA)
Back-Up O/C OUT * ON * LED BO 64 62 2 Yes
7163 50(N)/51(N) Backup O/C
PICKUP Phase B (5X-B Pickup
ØB)
Back-Up O/C OUT * ON * LED BO 64 63 2 Yes
7164 50(N)/51(N) Backup O/C
PICKUP Phase C (5X-B Pickup
ØC)
Back-Up O/C OUT * ON * LED BO 64 64 2 Yes
7165 50(N)/51(N) Backup O/C
PICKUP GROUND (5X-B Pickup
Gnd)
Back-Up O/C OUT * ON * LED BO 64 65 2 Yes
7191 50(N)-B1 Pickup (50(N)-B1
PICKUP)
Back-Up O/C OUT * ON m LED BO 64 91 2 Yes
7192 50(N)-B2 Pickup (50(N)-B2
PICKUP)
Back-Up O/C OUT * ON m LED BO 64 92 2 Yes
7193 51(N)-B Pickup (51(N)-B
PICKUP)
Back-Up O/C OUT * ON m LED BO 64 93 2 Yes
7201 50-STUB Pickup (50-STUB
PICKUP)
Back-Up O/C OUT * On
Off
m LED BO 64 101 2 Yes
7211 50(N)/51(N)-B General TRIP
command (5X-B TRIP)
Back-Up O/C OUT * * * LED BO 64 111 2 No
7221 50(N)-B1 TRIP (50(N)-B1 TRIP) Back-Up O/C OUT * ON * LED BO 64 121 2 No
7222 50(N)-B2 TRIP (50(N)-B2 TRIP) Back-Up O/C OUT * ON * LED BO 64 122 2 No
7223 51(N)-B TRIP (51(N)-B TRIP) Back-Up O/C OUT * ON * LED BO 64 123 2 No
7235 50-STUB TRIP (50-STUB TRIP) Back-Up O/C OUT * ON * LED BO 64 135 2 No
7250 67(N)-B1 Pickup (67(N)-B1
PICKUP)
Back-Up O/C OUT * on * LED BO
7251 67(N)-B2 Pickup (67(N)-B2
PICKUP)
Back-Up O/C OUT * on * LED BO
7252 67(N)-TOC Pickup (67(N)-TOC
PICK.)
Back-Up O/C OUT * on * LED BO
7253 67(N) General TRIP command
(67(N) TRIP)
Back-Up O/C OUT * on * LED BO
7254 67(N)-B1 TRIP (67(N)-B1 TRIP) Back-Up O/C OUT * on * LED BO
7255 67(N)-B2 TRIP (67(N)-B2 TRIP) Back-Up O/C OUT * on * LED BO
7256 67(N)-TOC TRIP (67(N)-TOC
TRIP)
Back-Up O/C OUT * on * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
