Siemens SIPROTEC 7SD80 User Manual

Appendix
A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
391
32100 >87L Protection blocking signal
(>87L block)
87 Diff. Prot. SP On
Off
**LEDBIBO
32102 87L Protection is active (87L
active)
87 Diff. Prot. OUT on * * LED BO
32103 87L Fault detection A (87L Fault
A)
87 Diff. Prot. OUT * On
Off
m LED BO
32104 87L Fault detection B (87L Fault
B)
87 Diff. Prot. OUT * On
Off
m LED BO
32105 87L Fault detection C (87L Fault
C)
87 Diff. Prot. OUT * On
Off
m LED BO
32107 87L Protection is blocked (87L is
blocked)
87 Diff. Prot. OUT on * * LED BO
32108 87L Protection is switched off
(87L is OFF)
87 Diff. Prot. OUT on * * LED BO
32109 87L A released (87L allow A) 87 Diff. Prot. OUT * * * LED BO
32110 87L B released (87L allow B) 87 Diff. Prot. OUT * * * LED BO
32111 87L C released (87L allow C) 87 Diff. Prot. OUT * * * LED BO
32112 87 CT primary ratio is too high (87
CTRatioAlarm)
87 Diff. Prot. OUT On
Off
**LEDBO
32113 87L receive blocking (87L receive
blk)
87 Diff. Prot. OUT On
Off
**LEDBO
32114 87L send blocking (87L send blk) 87 Diff. Prot. OUT On
Off
**LEDBO
32115 87L IDYN> A (87L IDYN> A) 87 Diff. Prot. OUT * On
Off
m LED BO
32116 87L IDYN> B (87L IDYN> B) 87 Diff. Prot. OUT * On
Off
m LED BO
32117 87L IDYN> C (87L IDYN> C) 87 Diff. Prot. OUT * On
Off
m LED BO
32118 87L ISTAT> A (87L ISTAT> A) 87 Diff. Prot. OUT * On
Off
m LED BO
32119 87L ISTAT> B (87L ISTAT> B) 87 Diff. Prot. OUT * On
Off
m LED BO
32120 >87N L Protection blocking signal
(>87N L block)
87 Diff. Prot. SP On
Off
**LEDBIBO
32121 >87N L: Protection is active
(>87N L active)
87 Diff. Prot. OUT on * * LED BO
32122 87(N)L Fault detection (87(N)L
Gen.Flt.)
87 Diff. Prot. OUT * On
Off
m LED BO
32124 >87N L: Fault detection of I-Diff>
(>87N L I> Flt.)
87 Diff. Prot. OUT * On
Off
m LED BO
32125 87(N)L General TRIP (87(N)L
Gen.TRIP)
87 Diff. Prot. OUT * On
Off
m LED BO
32126 87N L: Protection is blocked (87N
L block)
87 Diff. Prot. OUT on * * LED BO
32127 87N L: Protection is switched off
(87N L OFF)
87 Diff. Prot. OUT on * * LED BO
32128 87N L: detection 3V0> pickup
(87N L 3V0>)
87 Diff. Prot. OUT * On
Off
m LED BO
32129 87N L: detection Forward (87N L
Forward)
87 Diff. Prot. OUT * On
Off
m LED BO
32130 87N L: detection Reverse (87N L
Reverse)
87 Diff. Prot. OUT * On
Off
m LED BO
32131 87N L: detection Undef. Direction
(87N L UndefDir)
87 Diff. Prot. OUT * On
Off
m LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
