Control During Operation
224
7SS52 V4 Manual
C53000-G1176-C182-3
Please read the SIGRA Manual /4/ i f you want to know more about the numerous op-
tion SIGRA 4 offers.
To retrieve fault data of a single bay unit (PC linked to central unit or bay unit) proceed
as follows:
Open the corresponding bay unit in the DIGSI Manager.
Click Fault values in the navigation window.
Double-click Fault recording. The Select fault window opens (Figure 6-14, page
224).
Click SIGRA.... The fault data are retrieved and saved. SIGRA opens and the fault
data are loaded (see also the DIGSI Manual “Operation”, Subsection 8.3.3).
Figure 6-14 Select fault window in DIGSI
